Structure Synth

Structure Synth

Generate complex 3D geometry using rule-based procedural algorithms. Write programs in EisenScript (a simple domain-specific language) and watch as recursive rules create intricate 3D structures, organic forms, and architectural patterns.

Perfect for procedural art, architectural visualization, generative design, or any project where you need complex 3D geometry that would be tedious to model by hand.

This is based on the code from the original Structure Synth software, which was ported to ossia.

How it works

Structure Synth interprets EisenScript programs that define recursive rules for generating 3D geometry. You write rules that describe how shapes should transform, combine, and multiply, then the system executes these rules to build complex 3D meshes.

Be careful about having too much recursion: this will cause the mesh generation to take sometimes multiple seconds.

Ports and controls

Program contains the EisenScript source. Regenerate requests a new build, including a new realization of randomized rules. Position, Rotation and Scale place the generated mesh. The Geometry outlet can feed Model display, Render Pipeline or geometry filters.

Dropping an .es file creates a Structure Synth process with that program. Generation is an asynchronous mesh build, not per-frame shader evaluation: keep recursive rules bounded when automating program changes.

To add scene materials, connect Geometry to PBR Mesh, then Scene Preprocessor and a scene-aware renderer. See Instancing and materials and 3D scene pipeline.

EisenScript basics

The EisenScript language reference contains a recursive-box example, along with rule weights, transformations, termination controls and the upstream language manual.

Use Program to edit the grammar and Regenerate to rebuild its geometry. For animated camera motion or material changes, work downstream of this process rather than rebuilding the grammar on every frame.

Try it!

Try it by downloading this simple example!
