Classifier

The Classifier process provides real-time machine learning classification capabilities using RapidLib algorithms. It’s similar to tools such as Wekinator but integrated directly into score’s processing pipeline.

It is very close to the Regressor process: the difference is that Regressor interpolates while Classifier outputs the exact input value that was set during training.

Overview

The Classifier enables:

• Real-time pattern recognition
• Gesture classification
• Sensor data categorization
• Multi-class decision making
• Adaptive learning during performance

Perfect for:

• Interactive installations
• Gesture-controlled instruments
• Sensor-based interactions
• Adaptive audio/visual systems

Inputs

Outputs

Inputs

Outputs

Usage Workflow

1. Define Mapping

Decide what you want to map:

• Inputs : Sensor values, analysis data, control positions
• Outputs : Audio parameters, visual controls, device values

2. Data Collection

For each training point:

1. Set inputs to desired state
2. Set Target to desired outputs
3. Trigger Record
4. Repeat across your mapping space

3. Training and Use

Training Phase:
[Input State] → [Set Target] → [Record] → [Collect Examples] → [Train]

Runtime Phase:
[Live Input] → [Regressor] → [Smooth Output] → [Parameter Control]

Example Applications

Gesture Recognition

Recognize hand gestures from accelerometer data:

[Accelerometer] → [Feature Extraction] → [Classifier] → [Gesture Type]
                        ↓                                      ↓
                 [X, Y, Z, Magnitude]                   [Visual Response]

Training process:

1. Perform “wave” gesture, record as Class 1 (input knob at value 0)
2. Perform “circle” gesture, record as Class 2 (input knob at value 0.5)
3. Perform “tap” gesture, record as Class 3 (input knob at value 1.0)
4. Train the model
5. Real-time gesture recognition

Audio Classification

Classify different types of sounds:

[Audio Input] → [FFT] → [Spectral Features] → [Classifier] → [Sound Type]
                              ↓                                    ↓
                  [Centroid, Rolloff, ZCR]               [Trigger Actions]

Movement Classification

Classify dancer movements from video analysis:

[Camera] → [Pose Detection] → [Movement Features] → [Classifier] → [Dance Style]
                                     ↓                                    ↓
                          [Joint Velocities, Angles]            [Music Selection]

Feature Engineering

Good features are crucial for classification performance:

Common Feature Types

Time Domain:

• Mean, standard deviation
• Min, max values
• Zero crossing rate
• Peak locations

Frequency Domain:

• Spectral centroid
• Spectral rolloff
• MFCC coefficients
• Energy in bands

Motion Features:

• Velocity, acceleration
• Jerk (rate of acceleration change)
• Angular velocity
• Trajectory curvature

Feature Extraction Example

[Raw Sensor] → [Sliding Window] → [Statistics] → [Features]
                      ↓                 ↓
               [Buffer 100ms]    [Mean, Std, Peak]

Training Best Practices

Data Collection

1. Diverse Examples : Collect varied examples for each class
2. Balanced Dataset : Similar number of examples per class
3. Representative Data : Examples should cover expected variations
4. Clean Data : Remove obvious errors and outliers

Class Design

1. Distinct Classes : Make sure classes are meaningfully different
2. Consistent Labeling : Be consistent with class definitions
3. Sufficient Examples : At least 10-20 examples per class
4. Test Data : Keep some examples for testing

Performance Monitoring

• Check confidence scores
• Monitor misclassification patterns
• Retrain with additional data if needed

Integration Examples

Interactive Music

[Gesture Input] → [Classifier] → [Music Style]
                                      ↓
                                 [Instrument Selection]
                                 [Scale Selection]
                                 [Rhythm Pattern]

Adaptive Visuals

[Environmental Data] → [Classifier] → [Mood Classification]
                                             ↓
                                      [Color Palette]
                                      [Animation Speed]
                                      [Effect Selection]

Smart Lighting

[Activity Sensors] → [Classifier] → [Activity Type]
                                          ↓
                                   [Lighting Scene]
                                   [Color Temperature]
                                   [Brightness Level]

Related Processes

• Regressor - For continuous value prediction
• Analysis - Feature extraction from audio
• Computer Vision Utilities - Visual features
• Array Utilities - Feature preprocessing

Try it!

Try it by downloading this simple example!
